Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: AYAA
  • Model Number: uninterruptable ups power supply AY-T3000
  • Phase: Single Phase
  • Protection: Overvoltage
  • Weight: 30kg
  • Output Voltage: 220/230/240VAC
  • Type: Standby
  • Application: Military
  • Capacity: 51.8V 52AH
  • Battery Type: Li-ion battery built in
  • Wave Form: Pure Sine Wave Output
  • Color: Black
  • Transfer Time: 4ms (Generator Mode 8ms)
  • Frequency: 50HZ/60HZ
  • Certification: CE/ROSH/UL/MSDS/UN38.3
  • Display: High Definition LED
  • size: 560*450*200mm
  • peak power: 6000W

Packaging & Delivery

Packaging Details carton box, one unit in one box
Delivery Time Shipped in 7 days after payment

Medical Grade Power Supply AY-T3000W

Product Description



AY-T3000W is off line ,dual function portable AC power station with built-in UPS.

It is with capacity 12V 280AH/3360Wh and accurate pure wave AC 220V/50hz, 230V/50hz, DC 12V

10A.  AY-T3000W is designed with the safety lithium battery and inverter technology, which features

LED indicator digital display the energy of power, DC 48V and DC 12V dual output, etc.

The built-in main board  with multi protected function and Intelligent battery management board ensure

its safety for use.

AY-T3000W is applied to a variety of mobile products such as mobile phone, satellite phones, digital

cameras, mobile hard drives, cameras, tablet PC, LED lights, laptop computers, car boot, outdoor

lighting, water pump, medical equipment and so on, which  can be used for the following field such as first

aid, mining, exploration, military, scientific, media, tourism, disaster relief, medical aid.









Technical Parameter
AYAA Portable off-grid Home Power System
Model
ups Power Supply AY-GT3000W
Solar Panel (Optional)
Battery
Maximum Input Voltage
36V
Type
Li-ion
Input Power
720W
Capacity
51.8V 52AH
Environment
Inverter
Humidity
5RH to 95Rh
Continuous Power
3000W
Operating Temperature
-20 to 60℃
Surge Power
6000W
Storage Temperature
5 to 45℃
Output Voltage
220V/230V
Estimating Recharging Time
Output Wave Form
Pure Sine Wave
By Built-in Charger
6~8H
Phase
Single Phase
By Solar Panel

AC Receptacles
Universal
By Wind Turbine

Plug
EU/UK/USA/AU/CN
General Information
Peak Efficiency
88%
Accessories
Charger
No Load Battery Drew
6W
Product Dimension
 560*450*200mm
Transfer Time
5ms
Packing Dimension

AC Input Protection

Net Weight
 30Kg
Output Port
Gross Weight

Output (DC/AC)
12V       48V            220/230V
Office Back Up Power Application
Qty
1            2                  2
5W Cell Phone
600H
DC Charger
35W LCD Monitor
85.7H
Charger Current
10A
60W Table Lamp
50H
Charging Voltage
58.8V
65W Laptop
46H
Protection
Home Back Up Power Application
Over Temperature
65℃
80W Freezer
37.5H
AC Over Voltage
100~120V/ 200~240V
120W Fridge
25H
AC Short Circuit
Yes
700W Drill
4.2H
DC Short Circuit
Yes
1000W Micro Wave
3H
Protection Level
IP22
1200W Coffee Maker
2.5H
Purchase Tips

1.Please ensure the load for ups power supply is no more than 3000W

2.Matching electrical appliance with standard AC input

3.Matching city power standard frequency

4.Use matching DC output to power up your load

5.Evaluating your load if it has Surge Power( Instantaneous Power)

6.How much back up time do you want for your load

7.Please feel free to discuss with our engineer before purchase



load back up time calculation:

Ups power supply AY-T3000



3000     ÷load power cunsumption        ≈
